شناسنامه محصول (COA/TC) برای مفتول آلومینیوم؛ چه آیتم‌هایی باید درج شود؟

COA / TC — Aluminum Wire
Supplier: _____________     Plant/Line: _____________
Customer: _____________     PO/Contract No.: _____________
Standard/Spec: _____________ (ASTM/IEC/EN/Customer Spec)
Product: Aluminum Wire (Spool/Coil/Drum)
Alloy/Grade: ________     Temper: ________
Diameter: ____ mm  (Tol: ____ )   Ovality (if req.): ____
Heat No.: ________   Batch/Lot: ________   Date of Production: ____  Date of Issue: ____

Packaging:
Type: Spool/Coil/Drum   Unit weight (Net): ____ kg   Units in shipment: ____
Spool/Coil Nos. (Mapping to Heat/Batch): __________________________________

Test Results (Lot-specific if required):
1) Chemical composition (wt%) — Method: ________   Heat/Batch: ________
   (List elements as per alloy spec)  Result: __________

2) Mechanical — Method/Std: ________   Sample dia: ____ mm   n=__
   UTS: ____ MPa   Yield (if req.): ____ MPa   Elongation: ____ %

3) Electrical (if required) — Method/Std: ________   Temp ref: ____ °C
   Conductivity: ____ %IACS   Resistivity: ____ (unit)

4) Dimensional & Surface (if required) — Method: ________
   Diameter min/max: ____ / ____ mm   Surface: Clean / Wipe test: Pass/Fail

Statement of Conformity:
The supplied material conforms to the above specification and the test results are as stated.

Issued by (QC/Authorized Inspector): _____________  Signature: _____________  Date: _____________

1) COA/TC Requirement:
   Supplier shall provide COA/TC with each shipment. The document must be traceable to the delivered material.

2) Document Type / Level:
   Required inspection document type: (2.2 / 3.1 / 3.2) as per agreement.
   For 3.1/3.2, test results shall be lot-specific (related to the delivered batch/heat).

3) Mandatory Identification:
   Alloy/Grade, Diameter & tolerance, Temper (if applicable), Standard/Specification, Net weight,
   Heat No., Batch/Lot No., Production date, Issue date, and Packaging unit IDs (Spool/Coil/Drum Nos.).

4) Mandatory Test Items (as applicable to order):
   - Chemical composition (wt%) — include method/standard and related Heat/Batch
   - Mechanical: UTS, Elongation (and Yield if required) — include method/standard and sample details
   - Electrical (for electrical grade): Conductivity (%IACS) and/or resistivity — include temperature reference and method
   - Dimensional: diameter min/max and ovality (if required)
   - Surface cleanliness (if required): wipe test Pass/Fail

5) Acceptance / Hold:
   Missing Heat/Batch traceability, missing units/methods, or non-conforming document type may be basis for HOLD/Quarantine
   until corrected documentation is provided.

6) Authorization:
   COA/TC must be signed by Supplier’s authorized QC/inspection representative and include issue date.
